Allen-Bradley 800T-24HG17KB6AX 800T PB, 30mm Selector Switch, 2 Position Selector Switch, 24V AC/DC, Knob Lever Type, Green, KB6 Cam, KB6 Cam, Maintained, 24V AC/DC, No Guards - on Terminals, Incandescent Lamp, 1-NO 1-NC Standard Contacts
Allen-Bradley 800T-24HG17KB6AX 800T PB, 30mm Selector Switch, 2 Position Selector Switch, 24V AC/DC, Knob Lever Type, Green, KB6 Cam, KB6 Cam, Maintained, 24V AC/DC, No Guards - on Terminals, Incandescent Lamp, 1-NO 1-NC Standard Contacts
SKU: A-B800T24HG17KB6AX
Manufacturer Part Number: 800T-24HG17KB6AX
UPC: 662073424819
Documents
Features
Specification
| Hazardous Location | No |
|---|---|
| Head Type | Knob Lever |
| Illumination Options | Incandescent |
| Lens Color | Green |
| Operator Function | Maintained |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Cam Option | KB6 Maintained Cam |
| Catalog ID | A-B800T24HG17KB6AX |
| Contact Block First Level | 1 N.O. - 1 N.C. |
| Contact Block- Position 3- Second Level | No Contacts in this Position |
| Factory or User Assembled | Factory Assembled |
| Finger Safe Guards | No Guards |
| Power Module | Full Voltage |
| Voltage | 24V AC/DC |
