Appleton® UNILETS™ LB77 Type LB Conduit Outlet Body, 2-1/2 in Hub, 7, 102 cu-in, Grayloy Iron, Triple Coated
Appleton® UNILETS™ LB77 Type LB Conduit Outlet Body, 2-1/2 in Hub, 7, 102 cu-in, Grayloy Iron, Triple Coated
SKU: APPLB77
Manufacturer Part Number: LB77
UPC: 781381506762
Documents
Short Description
Features
- Serve as pulling fittings
- Make bends in conduit system
- Provide openings for splicing
- Connect and change direction of conduit runs
- Allow connections for branch runs
- Permit access to conductors for maintenance
- Smooth, rounded integral bushing in each hub protects conductor insulation
- Accurately tapped, tapered threads for tight, rigid joints and excellent ground continuity
- Completely interchangeable with Crouse-Hinds Form 7 bodies, gaskets and covers
- Equivalent FM7 and Form 7 units have identical applications and installation dimensions
- Flat back design provides greater cubic content for easier wire pulling and more room for splicing
- Fits flush and snug against flat surfaces for more stable installation
- Smooth hub openings allow easy conduit joining
- Hub size, body style, compliance data, maximum wire number/size and cubic capacity molded into body
- Stainless steel screws
- Triple Coat (Zinc Electroplated, Chromate and Epoxy Powder Coated)
Specification
| Hub Size | 2-1/2 in |
|---|---|
| Material | Grayloy Iron |
| Number of Hubs | 2 |
| Type | Type LB |
| Application | For Rigid/IMC Conduit |
| Standard & Approvals | UL 514A, 514B, E2527 Listed, CSA C22.2 NO 18.3 Certified, 065183 Certified, RoHS Compliant |
| Dimensions | 10.5 in L x 5.75 in W x 5.13 in H |
| Capacity | 102 cu-in |
| Color | Gray |
| Connection Type | Tapered FNPT |
| Enclosure | NEMA FB-1 |
| Finish | Triple Coat |
| Form | 7 |
