Austin Electrical Enclosures AB-12105JH Hinge Boxes, 12 in H x 10 in W x 5 in D, Screw Clamp Cover, NEMA 12/NEMA 13 Nema Rating, Steel
Austin Electrical Enclosures AB-12105JH Hinge Boxes, 12 in H x 10 in W x 5 in D, Screw Clamp Cover, NEMA 12/NEMA 13 Nema Rating, Steel
SKU: AUSAB-12105JH
Manufacturer Part Number: AB-12105JH
EAN: 0707353006955
UPC: 707353006955
Documents
Features
- Continuously Welded seams Ground Smooth
- Neoprene Gasket attached to cover with Oil Resistant Adhesive
- Cover held in place by Continuous Hinge on one side and stainless steel external screw clamps on opposite side
- External Mounting Feet
- Enclosures that are 6x4x3 and over have stand-offs provided for mounting optional panel or terminal kit
- Special Finishes
- Custom Size or Construction
- Hasp for padlocking
- 12 lb weight
Specification
| Type | Hinge Boxes |
|---|---|
| Standard & Approvals | CUL 508 Type 12, CUL 508 Type 13, UL 508 Type 12, UL 508 Type 13, NEMA Type 12, NEMA TYPE 13 |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Color | Gray |
| Finish | Polyester Powder Coated |
| Height | 12 in |
| Material | Steel |
| Width | 10 in |
| EANUCC13 | 0707353006955 |
| NEMA Rating | NEMA 12/NEMA 13 |
| Mounting Type | External Feet |
| Depth | 5 in |
| Cover Type | Screw Clamp |
| Catalog ID | AUSAB-12105JH |
