Baldor-Reliance FDL3507M Farm Duty Motor, 115/230 VAC, 4.4/8.8 A, 56 Frame, 0.75 hp, 1725 rpm
Baldor-Reliance FDL3507M Farm Duty Motor, 115/230 VAC, 4.4/8.8 A, 56 Frame, 0.75 hp, 1725 rpm
SKU: BDRFDL3507M
Manufacturer Part Number: FDL3507M
UPC: 781568121863
Features
- Ball bearings, lubricated with high temperature moisture resistant grease
- Condensation drains
- Gasketed cast conduit boxed
- Farm duty epoxy paint for protection from harsh environments
- 75 power factor
- Rigid base
Specification
| Frame | 56 |
|---|---|
| Frequency Rating | 60 Hz |
| Insulation Class | F |
| Material | Steel |
| Mounting Type | F1 |
| Number of Speeds | 1 |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Amperage Rating | 4.4/8.8 A |
| Bearing Type | Sealed |
| Catalog ID | BDRFDL3507M |
| Dimensions | 13.35 in L x 8.68 in H |
| Enclosure Type | TEFC |
| Phase | 1 |
| Rotation | Reversible |
| Service Factor | 1.25 |
| Shaft Size | 5/8 in Dia |
| Speed | 1725 rpm |
| Temperature Rating | 40 deg C |
| Torque Rating | 7 ft-lb |
| Voltage Rating | 115/230 VAC |
| Application | Agri-Duty and Industrial Applications |
| Standard & Approvals | CSA Certified, UR Standard |
| Horsepower | 0.75 hp |
