Belden® AX101308 KeyConnect Style Modular Jack, Cat 5e RJ45 Module, Keystone Mount, 1 Port, Plastic, Almond

Selected Belden® AX101308 KeyConnect Style Modular Jack, Cat 5e RJ45 Module, Keystone Mount, 1 Port, Plastic, Almond
Belden® AX101308 KeyConnect Style Modular Jack, Cat 5e RJ45 Module, Keystone Mount, 1 Port, Plastic, Almond

Documents

Short Description

The REVConnect connectivity system offers versatility by using a universal termination core and termination method for all RJ45 connections. Its unique universal termination process can be used with both shielded and unshielded cables, Category 5e through Category 6A and can accept both jack and plug housings. Both the new REVConnect CAT5E jacks and the CAT5E modular jacks provide performance margins when installed as part of 1200 System. Category 5E performance exceeds all parameters specified in the Category 5E standard. All performance characteristics have been set to guarantee transmission performance up to 160 MHz and a data-rate of up to 1.2 GB/sec.

Features

  • Provides excellent durability and performance stability
  • Offers performance margins for all gigabit network applications
  • Provides a safer work method and quicker installation
  • REVConnect offers great versatility and labor savings
  • Both modular jacks meet and exceed all Category 5E component performance
  • REVConnect requires no pair separation step, the best connector for bonded and non-bonded cable
  • REVConnect terminates 4 pairs simultaneously with Belden®'s universal termination tool
  • CAT 5E modular jacks compatible with Belden®'s rapid termination tool
  • Copper alloy with 50 u in gold over nickel front connection
  • Copper alloy with nickel plating rear connection
  • -10 to 60 deg C operating temperature
  • 1.5 A current, 500 MOhm insulation resistance
  • Compatible with interface and MDVO style faceplates, adapters, boxes and patch panels
  • Individually packaged in a plastic bag

Specification

Material
Plastic
Module Type
Cat5e/RJ45
Mounting Type
Keystone
Number of Ports
1
Dimensions
0.88 in H x 0.64 in W x 1.29 in D
Color
Almond
Standard & Approvals
FCC Part 68, Subpart F, IEC 60603-7, RoHS Compliant, ISO/IEC 11801:2002 Ed.2, ETL, ACA, Bi-National Standard Listed
Application
Indoor and Multi-Locations
Type
KeyConnect Style
Includes
T-Bar
