Blackburn® IKL69 Insulated Service Entrance Splice, 4/0 AWG ACSR/Stranded Conductor, Die Code: 840, 5-1/2 in L, Aluminum

Selected IKL69Blackburn® IKL69 Insulated Service Entrance Splice, 4/0 AWG ACSR/Stranded Conductor, Die Code: 840, 5-1/2 in L, Aluminum
IKL69Blackburn® IKL69 Insulated Service Entrance Splice, 4/0 AWG ACSR/Stranded Conductor, Die Code: 840, 5-1/2 in L, Aluminum

Documents

Short Description

Blackburn® stands for quality and reliability as a supplier of materials to connect overhead distribution power lines and equipment.

Features

  • All seasons/conditions environmental conditions
  • Pre-insulated for fast, easy installation of large home or commercial service entrances
  • Concave polyethylene end caps seal out dirt, but are easily pierced when inserting conductor
  • Use as a low tension reducing sleeve for insulated conductor
  • Can be used as a low-cost reducing sleeve
  • 840 die series, B49EA, 840 U-K840, U-249 hydraulic dies, BY37, 840 W-K840, TX mechanical dies
  • Color-coded and marked for easy identification
  • End A - 4/0 AWG ACSR, 4/0 AWG stranded, End B - 4/0 AWG ACSR, 4/0 AWG stranded
  • 25/Pack

Specification

Length
5-1/2 in
Material
Aluminum
Type
Insulated
Conductor Size
End A - 4/0 AWG ACSR/End B - 4/0 AWG ACSR
Connector Type
Crimp/Compression
Standard & Approvals
ANSI C119.4 Compliance, RoHS Compliant, RUS Accepted
Application
For Combinations of Aluminum to Aluminum and Aluminum to Copper Conductors
Specifications
2-Conductors, 0.522 - 0.564 in Dia End A, 0.522 - 0.564 in Dia Max End B
Color
Pink
Die Code
840
Conductor Type
Stranded/ASCR/Compact Copper/Aluminum
