BURNDY® VERSI-POLE™ BDBLHC223501 VERSIPOLE Terminal Block Cover, 600 V AC, 620 A, 1 Poles, 6 AWG to 350 kcmil Wire, Aluminum

Selected BURNDY BDBLHC245001
BURNDY BDBLHC245001

Documents

Short Description

These Power Distribution Blocks are Listed to the Power Distribution Block Standard UL 1953. They contain the same features and characteristics as the non-Listed blocks however, these have spacing's that are suitable for installations in most industrial control panel feeder and branch circuits, HVAC systems, and Wire ways (with optional cover; sold separately). They are available in one, two, or three pole configurations. An "Adder" is also available with optional End Barrier (sold separately), to allow user customized configurations.

Features

  • 6 AWG to 350 kcmil tap and 6 AWG to 350 kcmil run cable

Specification

Material
Aluminum
Short Circuit Current Rating
100 kA
Number Of Poles
1
Wire Size
6 AWG to 350 kcmil
Finish
Tin Plated
Dimensions
5.7 in L x 2.73 in W x 3.55 in H
Amperage Rating
620 A
Voltage Rating
600 V AC
Series
VERSIPOLE
