BURNDY® UNITAP™ BIT4FX Type 3A Bit Insulated Multi-Tap Connector, 14 to 4 AWG, 14 to 6 AWG Aluminum/Copper/Stranded Conductor, Aluminum
BURNDY® UNITAP™ BIT4FX Type 3A Bit Insulated Multi-Tap Connector, 14 to 4 AWG, 14 to 6 AWG Aluminum/Copper/Stranded Conductor, Aluminum
SKU: BURBIT4FX
Manufacturer Part Number: BIT4FX
UPC: 621945440036
Documents
Features
- Clear plastisol covered AL6061-T6 aluminum body
- Saves time
- Lowers installation costs
- Eliminates taping
- Oxide inhibitor pre-installed
- Inhibits moisture and contaminants from entering the contact area
- Opposite sided entry
- Flex conductor rated
- 14 to 4 AWG aluminum, 14 to 6 AWG copper
Specification
| Material | Aluminum |
|---|---|
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Catalog ID | BURBIT4FX |
| Conductor Size | 14 to 4 AWG |
| Conductor Type | Aluminum/Stranded Copper |
| Dimensions | 1.08 in L x 1.13 in W x 1.25 in H |
| Finish | Tin Plated |
| Specifications | 2-Ports, 1/8 in Hex Key, Plastisol Insulation |
| Temperature Rating | -40 to 135 deg C |
| Type | Type 3A BIT |
| Voltage Rating | 600 VAC |
| Standard & Approvals | PROP65: This product can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
