BURNDY® VINYLUG™ TP106 TP Series Type TP Ring Terminal, 12 to 10 AWG Conductor, 0.68 in L, Deep V-Groove Serrated Barrel, Electrolytic Copper, Blue

Selected TP10-6BURNDY® VINYLUG™ TP106 TP Series Type TP Ring Terminal, 12 to 10 AWG Conductor, 0.68 in L, Deep V-Groove Serrated Barrel, Electrolytic Copper, Blue
TP10-6BURNDY® VINYLUG™ TP106 TP Series Type TP Ring Terminal, 12 to 10 AWG Conductor, 0.68 in L, Deep V-Groove Serrated Barrel, Electrolytic Copper, Blue

Documents

Short Description

BURNDY's compression connectors are designed for reliable and controllable electrical connections. The complete installation is fully inspectable. They are high conductivity copper and operate cooler than the wire on which they are installed. The connectors withstand a wide range of electrical and environmental conditions, including current surges, temperatures, corrosion and vibrations, for a wide variety of applications. These features mean a consistently high quality connection at a low installed cost. Copper compression connectors are manufactured from high-conductivity electrolytic copper. The connectors are normally tinplated, lead-plated, or plated with proprietary BURNDY® brite finish to provide durable long-lasting corrosion resistance. The connector design has been matched to the cable size to provide the necessary physical strength requirements for reliable electrical performance.

Features

  • Expanded insulation support accepts standard and large wire diameters lowers inventory requirements, permits greater flexibility and provides insulation support
  • Funnel entry provides easy wire insertion
  • Manufactured of pure electrolytic copper that provides maximum conductivity, low resistance and ductility for excellent crimp forming properties
  • Deep V groove serrations in the inner barrel provides added holding strength and better conductivity
  • Electro-tin plated provides durable long lasting corrosion resistance
  • For plier type: Y10-22, Y10D Or ratchet tool: MR8-89-1, MR15, M8ND with N10HET-23, TFM tool with DFM1D5 die
  • Supplied with an expanded polyvinyl chloride (PVC) insulation shroud
  • 12 - 10 AWG stranded/solid conductor size
  • Pure electrolytic tin plated copper
  • 0.26 in Dia Maximum Insulation, 19/64 in L Strip, 0.75 in Hole Centre to Barrel End, 0.2 in Hole Centre to Barrel

Specification

Length
0.68 in
Material
Copper
Overall Length
0.91 in
Series
TP
Stud Size
NO 4-6
Temperature Rating
105 deg C
Tongue Size
0.31 in W x 0.04 in THK
Tongue Style
Ring
Voltage Rating
600 VAC
Application
For Commercial and Light Duty Industrial Control and Power Circuit Applications
Standard & Approvals
UL 467, CSA Certified and RoHS Compliant
Conductor Size
12 to 10 AWG
Barrel Size
0.34 in L
Color
Yellow
Conductor Type
Copper
