Bussmann® ATC-30 Fast Acting Automotive Fuse, 30 A, 32 VDC, 1 kA

Selected ATC-30Bussmann® ATC-30 Fast Acting Automotive Fuse, 30 A, 32 VDC, 1 kA
ATC-30Bussmann® ATC-30 Fast Acting Automotive Fuse, 30 A, 32 VDC, 1 kA

Short Description

A range of UL® Recognized fast-acting ATC blade fuses for automotive and low voltage control circuits. Featuring the same form, fit, and electrical and performance characteristics, ATC fuses are available in a variety of housing materials specific to orderable catalog numbers to meet application needs.

Features

  • Industry standard color-coding for quick identification of amp rating
  • Tin-plated zinc terminals for corrosion resistance and enhanced conductivity
  • Wide -40 deg C to 100 deg C operating temperature range meets the needs of extreme environments
  • Lead free, halogen free
  • Test points on specific part/package numbers may speed up circuit troubleshooting
  • UL 94 housing flammability rating

Specification

Interrupt Rating
1 kA
Length
18.7 mm
Material
Polycarbonate
Mounting Type
Holder
Minimum Order Qty
1
Order Interval
1
Video
https://www.youtube.com/watch?v=YMvqUyoETXk
Amperage Rating
30 A
Catalog ID
BUSATC-30
Color
Green
Depth
5.1 mm
Element
Single
Voltage Rating
32 VDC
Application
Low Voltage Control Circuits
Standard & Approvals
ISO 8820-3/SAE J1284/JASO 612, SAE J1171, UL File No. E56412, Guide JFHR2, UL 248-1, RoHS Compliant
Terminal Type
Blade
