Bussmann® DFJ-175 Current Limiting High Speed Drive Fuse, 175 A, 600 VAC/450 VDC, 200/100 kA, Class J, Cartridge Body

Selected Bussmann® DFJ-175 Current Limiting High Speed Drive Fuse, 175 A, 600 VAC/450 VDC, 200/100 kA, Class J, Cartridge Body
Bussmann® DFJ-175 Current Limiting High Speed Drive Fuse, 175 A, 600 VAC/450 VDC, 200/100 kA, Class J, Cartridge Body

Short Description

The Bussmann series DFJ drive fuse is a high speed, current limiting fuse that provides maximum protection for AC and DC drives and controllers and meet NEC® branch circuit protection requirements. The drive fuse has the lowest I2t of any branch circuit fuse to protect power semiconductor devices that utilize diodes, GTOs, SCRs and SSRs.

Features

  • Easily coordinated with existing and new variable speed drives and electric controllers
  • Standard class J dimensions allow using readily available fuse blocks, holders and switches
  • Allows the lowest let through energy of any branch circuit overcurrent protective device
  • Silver fuse element

Specification

Interrupt Rating
200/100
Material
Melamine
Mounting Type
Stud
Amperage Rating
175 A
Voltage Rating
600 VAC/450 VDC
Body Type
Cartridge
Class
J
Element
Single
Indicating/Non-Indicating
Non-Indicating
Standard & Approvals
ARRA Compliant, Buy American Act Compliant, RoHS Compliant, PROP65: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Terminal Type
Blade
Rejection/Non-Rejection
Non-Rejection
Body Size
1.63 in Dia x 5.75 in L
Application
AC/DC Drives and Equipment using Power Semiconductor Devices Protection
