Bussmann® CUBEFuse® FCF20RN Fast Acting Fuse, 20 A, 600 VAC/VDC, Rectangle Body

Selected Bussmann® CUBEFuse® FCF20RN Fast Acting Fuse, 20 A, 600 VAC/VDC, Rectangle Body
Bussmann® CUBEFuse® FCF20RN Fast Acting Fuse, 20 A, 600 VAC/VDC, Rectangle Body

Short Description

Eaton's Bussmann® series fast-acting CUBEFuse™ delivers a faster response to damaging faults to help reduce to help reduce destructive thermal and magnetic forces. It is ideally suited for UPS and other critical applications. The industry - first finger safe CUBEFuse is a Class CF fuse that provides the same electrical performance as a Class J fuse, but with a significantly smaller footprint.

Features

  • Class CF meets Class J fast acting electrical performance requirement
  • Faster response to damaging faults to help reduce destructive thermal and magnetic forces
  • True fast acting fuse construction
  • High interrupting rating to safely interrupt faults up to 300 kA
  • No venting of arc or molten metal and gases during opening
  • Low let-through currents under fault conditions
  • Smallest footprint of any class fuse including Class J, CC, T and RK
  • The world's first finger-safe power fuse system

Specification

Mounting Type
Hole
Minimum Order Qty
1
Order Interval
1
Indicating/Non-Indicating
Non-Indicating
Amperage Rating
20 A
Body Size
1.88 in L x 0.75 in W
Body Type
Rectangle
Catalog ID
BUSFCF20RN
Voltage Rating
600 VAC/VDC
Application
UPS and Critical Applications
Standard & Approvals
UL E4273 Listed, CSA 1422- 02 Certified, CE Marked, RoHS Compliant
