Bussmann® FWH Fast Acting High Speed Semiconductor Fuse, 150 A, 500 VAC/VDC, 200/50 kA Interrupt, Cartridge Body

Selected BUSFWH 150B
BUSFWH 150B

Documents

Short Description

Eaton offers a complete range of North American blade and Flush end style fuses and accessories. North American style fuses provide an excellent solution for medium power applications. While there are currently no published standards for these fuses, the industry has standardized on mounting centers that accept Bussmann® series fuses.

Features

  • Excellent DC performance
  • Low arc voltage and low energy let-through (I2t)
  • Superior cycling capability
  • North American style
  • 200 kA at 500 VAC/50 kA at 500 VDC interrupt rating

Specification

Frequency Rating
45 - 1000 Hz
Interrupt Rating
200/50 kA
Material
Ceramic
Mounting Type
Stud
Minimum Order Qty
1
Order Interval
1
Video
https://www.youtube.com/watch?v=YMvqUyoETXk
Amperage Rating
150 A
Body Style
Cartridge
Element
Single
Voltage Rating
500 VAC
Terminal Type
Standard Blade
Standard & Approvals
UL Listed, CE Certified, CSA Certified, RoHS Complaint
Application
DC Common Bus, DC Drives, Power Converters/Rectifiers and Reduced Voltage Starters
Catalog ID
BUSFWH-150B
Body Size
1-5/32 in Dia x 3-5/8 in L
