Bussmann Limitron™ JKS-125 Current Limiting Fast Acting Fuse, 125 A, 600 V, 200 kAIC Interrupt, J Class, Cartridge Body

Selected Bussmann JKS 110
Bussmann JKS 110

Documents

Short Description

Bussmann's UL Class J fuse products extend both our Low-Peak family of products with our LPJ_SP and LPJ_SPI dual-element, time-delay fuses as well as our Limitron line offering fast-acting JKS fuses. The LPJ fuses provide industry leading 300,000 amp interrupting rating at 600Vac RMS Sym and 100kA Vdc while delivering a minimum of 10 seconds of 500 percent rated current ride-through performance which is ideal for sizing of high inrush loads. The LPJ products are available with optional permanent replace fuse indication. These UL Class J products in sizes 1 to 600 amps provide exceptional performance at 600 Vac and 300 Vdc (see spec sheets for specific details) in a compact size rejecting footprint

Features

  • Provides component short circuit protection in compliance with NEC 110-10 where protection devices shall clear a fault without extensive damage to the circuit components
  • High interrupt rating helps meet the requirements of future system expansion and the increases in available utility short circuit current
  • Fuses can be selectively coordinated with ease
  • Current limitation for non-inductive circuits provides class J current limiting response to maximum ground fault and short circuit conditions
  • Economical solutions for high fault circuits
  • Advanced protection
  • 200 kA interrupt rating provides high ratings at all circuit locations
  • Protects low interrupting capacity circuit breakers, limits the short circuit current to meet the interrupting capacity requirements of existing equipment
  • Well suited for lighting and heating circuits and other non-inductive loads

Specification

Series
JKS
Body Type
Cartridge
Material
Melamine
Rejection/Non-Rejection
Non-Rejection
Type
Current Limiting Fast Acting
Body Size
1-1/2 in Dia x 5-3/4 in L
Voltage Rating
600 V
Element
Single
Amperage Rating
125 A
Mounting Type
Holder
Indicating/Non-Indicating
Non-Indicating
Class
J
Interrupt Rating
200 kAIC
Terminal Type
Bolted Blade End
