EATON Arrow Hart™ Eaton Wiring Devices 183BK-BOX Non-Grounding Straight Blade Plug, 125 VAC, 15 A, 2 Poles, 2 Wires, Black

Selected 183BK-BOXEATON Arrow Hart™ Eaton Wiring Devices 183BK-BOX Non-Grounding Straight Blade Plug, 125 VAC, 15 A, 2 Poles, 2 Wires, Black
183BK-BOXEATON Arrow Hart™ Eaton Wiring Devices 183BK-BOX Non-Grounding Straight Blade Plug, 125 VAC, 15 A, 2 Poles, 2 Wires, Black

Documents

Short Description

Standard Grade - Rubber Plugs Non-Grounding Angle plugs allow placement of cord in convenient location. Plug blades are firmly embedded in body. Terminal screws backed out-ready for wiring.

Features

  • Plug blades are firmly embedded in body
  • Rubber plugs & connectors maintain flexibility in low temperatures
  • Angle plugs allow placement of cord in convenient location
  • Terminal screws backed out and ready for wiring
  • Combination Slot/Phillips head mounting and terminal screws for installation flexibility (Slot/Robertson screws in Canada where available)
  • Standard grade
  • Non-grounding
  • 10 - 18 AWG

Specification

Grade
Commercial
Material
Rubber
NEMA Rating
NEMA 1-15P
Number Of Poles
2
Number of Wires
2
Temperature Rating
-20 to 70 deg C
Terminal Type
Screw
Voltage Rating
125 VAC
Standard & Approvals
CSA Certified, NOM Certified (426), RoHS Compliant, UL listed
Amperage Rating
15 A
Dimensions
1.17 in W x 0.73 in D
Color
Black
Cord Diameter
0.33 in
