Crouse-Hinds Condulet® C39 Type C Conduit Outlet Body, 1 in Hub, Mark 9, 12 cu-in, Copper Free Aluminum, Natural

Selected FilesCHNC39
FilesCHNC39

Documents

Short Description

EATON Crouse-Hinds series is designed to the highest standard of safety and productivity to keep people safe and plants running reliably. The more demanding the environment, the likelier you are to find EATON products at the center of operations.

Features

  • Act as pull outlets for conductors being installed
  • Provide openings for making splices and taps in conductors
  • Act as mounting outlets for lighting fixtures and wiring devices
  • Connect conduit sections
  • Provide taps for branch conduit runs
  • Make 90 deg bends in conduit runs
  • Provide for access to conductors for maintenance and future system changes
  • Conduit hubs have tapered threads and feature integral bushing for protection of wire insulation
  • Exclusive SNAPTIGHT and wedge nut cover attachment to provide clear, unobstructed cover opening

Specification

Hub Size
1 in
Material
Copper Free Aluminum
Number of Hubs
2
Minimum Order Qty
1
Order Interval
1
Connection Type
NPT
Enclosure
NEMA 3R
Finish
Natural
Form
Mark 9
Standard & Approvals
ARRA, Buy American Act and RoHS Compliant, CSA C22.2, Federal Spec W-C-586D, UL 514B
Application
Rigid Conduit
Type
Type C
Dimensions
16-19/32 in L x 1-3/4 in W x 1-7/8 in H
Catalog ID
CHNC39
Capacity
12
