Crouse-Hinds EDSC3230 ESD Dust Ignitionproof Explosionproof Raintight Enclosure, 5-3/32 in L x 7-3/16 in W x 3-1/16 in H, NEMA 3/7B/7C/7D/9E/9F/9G/12 NEMA Rating, Feraloy® Iron Alloy
Crouse-Hinds EDSC3230 ESD Dust Ignitionproof Explosionproof Raintight Enclosure, 5-3/32 in L x 7-3/16 in W x 3-1/16 in H, NEMA 3/7B/7C/7D/9E/9F/9G/12 NEMA Rating, Feraloy® Iron Alloy
SKU: CHNEDSC3230
Manufacturer Part Number: EDSC3230
UPC: 782274765990
Documents
Short Description
Features
- Small and compact in design
- Mounting lugs and taper tapped hubs with integral bushings
- Large machine screws for fastening covers to bodies
- Lockout hole for padlock having 1/4 in hasp is provided
- Threaded type shafts and bushings are used to insure flame tightness
- To prevent arcing of enclosed switch from causing ignition of a specific hazardous atmosphere or atmospheres external to the enclosure
- In non-hazardous areas where sturdy, durable enclosures are required
- 3-way, 2-gang
- Stainless steel shafts and shaft bushings
- Raintight
- With general use snap switch front operated
Specification
| NEMA Rating | NEMA 3/7B/7C/7D/9E/9F/9G/12 |
|---|---|
| Application | Chemical Plants, Oil, Gas Refineries, Paint, Varnish Manufacturing Plants, Gasoline Bulk Loading, Terminals, Grain Elevators and Grain Processing Applications |
| Standard & Approvals | Class I, Division 1/2, Group C/D, Class II, Division 1, Group E/F/G, Class II, Division 2, Group F/G, Class III, UL 1203, CEC Certified, CSA C22.2 File No. 30, NEC Certified |
| Width | 7-3/16 in |
| Type | Dust Ignitionproof Explosionproof Raintight |
| Series | ESD |
| Mounting Type | Flush/Wall |
| Material | Feraloy® Iron Alloy |
| Length | 5-3/32 in |
| Height | 3-1/16 in |
| Electrical Ratings | 20 A at 120/277 VAC |
| Includes | General Use Snap Switch Front Operated |
| Finish | Electro-Galvanized/Aluminum Acrylic Painted |
