Crouse-Hinds Champ® Pro PVML-9-UNV34 Type V Optic Dimmable Standard LED Light Fixture, LED Lamp, 73 W Fixture, 347 to 480 VAC, Corro-Free™ Epoxy Powder Coated Housing

Selected VMVL-7-UNV1Crouse-Hinds Champ® Pro PVML-9-UNV34 Type V Optic Dimmable Standard LED Light Fixture, LED Lamp, 73 W Fixture, 347 to 480 VAC, Corro-Free™ Epoxy Powder Coated Housing
VMVL-7-UNV1Crouse-Hinds Champ® Pro PVML-9-UNV34 Type V Optic Dimmable Standard LED Light Fixture, LED Lamp, 73 W Fixture, 347 to 480 VAC, Corro-Free™ Epoxy Powder Coated Housing

Documents

Short Description

Crouse-Hinds series Champ® Pro PVML LED fixtures are designed to provide full-spectrum, crisp, white light for industrial mid bay and high bay down lighting applications. The PVML LED is available in nine models ranging from 3000 to 25000 Lumens. This offers a lighting solution for areas with mounting heights from 8 ft all the way up to 60 ft. PVML LED light fixtures are engineered to provide maintenance-free operation, while delivering long life and high Lumens performance. The NEMA 4X fixture provides up to 127 Lumens/W and custom type I, III and V optics maximize light distribution and intensity. These light fixtures are ideal for indoor and outdoor general area lighting where extremely corrosive, wet, dusty, hot and/or cold conditions exist. Typical installations include heavy industrial, mine site processing areas, platforms, loading docks, tunnels, indoor/outdoor spotlighting, outdoor wall and stanchion mounted general area lighting, and areas requiring frequent on-and-off of lights.

Features

  • Nine models from 3000 to 25000 Lumens for areas with mounting heights of 8 to 60 ft
  • Die cast aluminum heat sink increases surface areas and improves airflow, optimizing both LED and driver life, the PVML LED has a rated life of 60000 hr at 55 deg C ambient and its economic life ranges from 7 to 20 years
  • Energy efficient technology up to 77% energy savings over HID fixtures
  • Shock and vibration-resistant solid state luminaires have no filaments or glass components that could break greatly reduces the risk of premature failure
  • Custom type V optics distribute the light where it is needed most and can help reduce the number of fixtures required for certain lighting applications
  • Contractor friendly PVML LED utilizes the same mounting modules as our legacy HID luminaires, simplifying installation and reducing costs in retrofit projects
  • Instant illumination and restrike
  • Cold temperature operation/no warm-up required
  • Contains no mercury or other hazardous substances
  • -40 to 65 deg C operating ambient temperature
  • Without guard lens
  • Without mounting module

Specification

Housing Finish
Corro-Free™ Epoxy Powder Coated
Housing Material
Die Cast Aluminum
Lamp Type
LED
Lens Type
Clear Glass
Light Color
Cool White
Light Output
126 Lumens/W
Lumens
9234 Lumens
Series
PVML
Type
Type V Optic Dimmable Standard
Voltage Rating
347 to 480 VAC
Application
Industrial Facilities and Factories - Lighting and Lighting Control
Standard & Approvals
CE Certified, CSA C22.2 File No. 250, cUL Listed, DesignLights Consortium® Qualified, NEC/CEC Certified, UL 1598, UL 1598A
Amperage Rating
0.2 to 0.14 A
Dimensions
13 in L x 12.75 in W x 13.13 in H
Average Life
60000 hr
Color Rendering Index (CRI)
70
Color Temperature
5000 K
Enclosure Type
NEMA 4X/IP66
Fixture Wattage
73 W
