Crouse-Hinds VMV5LR1/UNV1 VMV Explosionproof Luminaire, LED Lamp, 43 W Fixture, 120 to 277 VAC, Corro-Free Epoxy Powder Coated Housing
Crouse-Hinds VMV5LR1/UNV1 VMV Explosionproof Luminaire, LED Lamp, 43 W Fixture, 120 to 277 VAC, Corro-Free Epoxy Powder Coated Housing
SKU: CHNVMV5LR1/UNV1
Manufacturer Part Number: VMV5LR1/UNV1
UPC: 662276360648
Short Description
Features
- Instant illumination and restrike
- Cold temperature operation/no warm-up required
- Easy installation compact modular fixture attaches onto existing Champ® mounting module
- Energy efficient technology up to 64% energy savings over HID fixtures
- Contains no mercury or other hazardous substances
- Shock and vibration resistant solid state luminaires have no filaments or glass components that could break greatly reduces the risk of premature failure
- 5 years fixture warranty
- Type I optic
- Ideal for mining conveyor belts, aisleways and hallways, catwalks and walkways, ramps and loading docks, tunnels with overhead mounts
- -40 to 65 deg C ambient temperature
- Heat and impact resistant glass lens
- Silicone gaskets, stainless steel external hardware
- >0.9 power factor
- 124 Lumens/W
Specification
| Housing Finish | Corro-Free Epoxy Powder Coated |
|---|---|
| Housing Material | Die Cast Aluminum |
| Lamp Type | LED |
| Lamp Wattage | 67 W |
| Lens Type | Glass |
| Light Color | White |
| Lumens | 5335 Lumens |
| Mounting Type | Fixture |
| Amperage Rating | 0.35 to 0.16 A |
| Voltage Rating | 120 to 277 VAC |
| Application | High/Low Bay for Heavy Industrial Plants, Refineries, Petrochemical Plants, Mining, Platforms, Loading Docks and Tunnels Applications |
| Average Life | 60000 |
| Color Rendering Index (CRI) | 70 |
| Color Temperature | 5000 |
| Enclosure Type | IP66 |
| Fixture Wattage | 43 W |
| Standard & Approvals | ARRA, Buy American Act and RoHS Compliant, DLC Listed, NEC, CEC, CSA, IEC, ATEX, CE Certified, UL 1598, 1598A, 844, CSA C22.2 |
