EATON A202K1BAM Magnetically Held Lighting Contactor, 110/120 VAC Coil, 2 Poles

Selected A202K1BAMEATON A202K1BAM Magnetically Held Lighting Contactor, 110/120 VAC Coil, 2 Poles
A202K1BAMEATON A202K1BAM Magnetically Held Lighting Contactor, 110/120 VAC Coil, 2 Poles

Documents

Short Description

Eaton's lighting contactors are designed to provide a safe, convenient means for local or remote switching of tungsten (incandescent filament) or ballast (fluorescent and mercury arc) lamp loads. They are also suitable for other loads such as low-pressure and high-pressure sodium lamp loads and other non-motor (resistive) loads. Our lighting contactors deliver unprecedented versatility in application, simplicity in configuration and performance in operation.

Features

  • Convenient side access for field power wiring
  • Three point mounting for fast, sure and easy installation
  • Finger and back of hand safe power terminals for added safety
  • Enclosed contacts resist contaminants for greater reliability
  • On-site configuration enables customers to quickly convert and adapt products to changing application needs
  • Components can be stocked rather than stocking already assembled contactors, freeing up space and reducing inventory

Specification

Frequency Rating
60 Hz
Number Of Poles
2
Coil Voltage
120 VAC
Enclosure Type
Open
Maximum Load Current
30 A
Dimensions
3.31 in L x 3.31 in W x 4.38 in H
Standard & Approvals
UL File No. E44424, UL Guide NRNT, CSA File No. LR39402, CSA Class 3231-01, NEMA ICS-2
Application
Office, Buildings, Industrial Plants, Hospitals, Stadiums and Airports
Type
Magnetically Latched
Terminal
Box Lug
Series
A202
