EATON BJ2125 Type BJ Main Circuit Breaker, 120/240 VAC, 125 A, 10 kA Interrupt, 2 Poles, Common/Thermal Magnetic Trip
EATON BJ2125 Type BJ Main Circuit Breaker, 120/240 VAC, 125 A, 10 kA Interrupt, 2 Poles, Common/Thermal Magnetic Trip
SKU: C-HBJ2125
Manufacturer Part Number: BJ2125
UPC: 786676367004
Documents
Features
- Requires at least a 150 A loadcenter, breaker uses two 1 in pole spaces and two 1 in pole spaces on right side of loadcenter
- Copper/aluminum wire
Specification
| Interrupt Rating | 10 kA |
|---|---|
| Mounting Type | Plug-On |
| Number Of Poles | 2 |
| Temperature Rating | 60 to 75 deg C |
| Trip Type | Common |
| Type | Type BJ Thermal Magnetic |
| Voltage Rating | 120/240 VAC |
| Wire Size | 2 to 300 KCMIL |
| Standard & Approvals | UL 489 |
| Amperage Rating | 125 A |
| Dimensions | 6-1/2 in L x 3-1/2 in W x 2-1/2 in H |
