EATON BR120ST Type BR Circuit Breaker, 120/240 VAC, 20 A, 10 kA Interrupt, 1 Poles, Instantaneous/Long Time/Thermal Magnetic/Shunt Trip
EATON BR120ST Type BR Circuit Breaker, 120/240 VAC, 20 A, 10 kA Interrupt, 1 Poles, Instantaneous/Long Time/Thermal Magnetic/Shunt Trip
SKU: C-HBR120ST
Manufacturer Part Number: BR120ST
UPC: 786676000161
Documents
Features
- Requires one 1 in space
- 14 to 4 AWG copper/aluminum wire range
Specification
| Interrupt Rating | 10 kA |
|---|---|
| Mounting Type | Plug-On |
| Number Of Poles | 1 |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Amperage Rating | 20 A |
| Catalog ID | C-HBR120ST |
| Dimensions | 2.5 in L x 1 in W x 2 in H |
| Phase | 1 |
| Temperature Rating | 40 deg C |
| Trip Type | Thermal Magnetic |
| Type | Type BR |
| Voltage Rating | 120/240 VAC |
| Wire Size | 14 to 4 AWG |
| Application | For use with Type BR load centers |
| Standard & Approvals | UL 489, Federal Specification W-C375 |
