EATON BR130 Type BR Circuit Breaker, 120/240 VAC, 30 A, 10 kAIC Interrupt, 1 Poles
EATON BR130 Type BR Circuit Breaker, 120/240 VAC, 30 A, 10 kAIC Interrupt, 1 Poles
SKU: C-HBR130
Manufacturer Part Number: BR130
UPC: 786676362207
Documents
Features
- Common trip requires one 1 in space
- All BR circuit breakers have rejection tab feature
- Units feature a quick-make, quick break switch mechanism combined with inverse time element tripping operation and trip-free handle design
- For single pole circuit breakers carry listing for HACR application
Specification
| Interrupt Rating | 10 |
|---|---|
| Mounting Type | Plug-On |
| Number Of Poles | 1 |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Amperage Rating | 30 A |
| Catalog ID | C-HBR130 |
| Dimensions | 3 in L x 1 in W x 3 in H |
| Enclosure Type | NEMA 1/3R/4X |
| Phase | 1 |
| Temperature Rating | 60 to 75 deg C |
| Trip Type | Thermal Magnetic |
| Type | Type BR |
| Voltage Rating | 120/240 VAC |
| Wire Size | 14 to 4 AWG |
| Standard & Approvals | CSA Certified, NEMA Standards, UL 489, Federal Specification W-C375 |
