EATON C25DNJ250A D-Frame Non-Reversing Definite Purpose Control Contactor With Metal Mounting Plate, 110 to 120 VAC at 50/60 Hz V Coil, 50 A, 2 Poles

Selected C25DNJ250AEATON C25DNJ250A D-Frame Non-Reversing Definite Purpose Control Contactor With Metal Mounting Plate, 110 to 120 VAC at 50/60 Hz V Coil, 50 A, 2 Poles
C25DNJ250AEATON C25DNJ250A D-Frame Non-Reversing Definite Purpose Control Contactor With Metal Mounting Plate, 110 to 120 VAC at 50/60 Hz V Coil, 50 A, 2 Poles

Documents

Short Description

Eaton offers the most comprehensive line of definite purpose contactors in the industry. Initially designed as an HVAC and refrigeration product, the C25 line is now the market leader and the product of choice for many OEM and contractors serving diverse markets. Featuring current ratings between 15A and 360A, the contactors are dual-rated for inductive and resistive ratings as well as for horsepower and kilowatt ratings.

Features

  • Highest electrical life in its class-minimum 250000 operations
  • 15 to 50 A, two and three-pole contactor frame size
  • Open with metal mounting plate
  • 65 A resistive per pole

Specification

Frequency Rating
50/60 Hz
Maximum Load Current
50 A
Number Of Poles
2
Minimum Order Qty
1
Order Interval
1
Coil Voltage
110 to 120 VAC
Enclosure Type
Open
Series
C25
Terminal
Box Lug/Quick Connect (Vertical In-Line)
Type
Non-Reversing
Standard & Approvals
UL File No. E1491 (Guide No. NLDX2), CSA, CE Certified, ROHS Compliant
Dimensions
4 in L x 2.6 in W x 3.8 in H
Contact Type
Double Break
Coil Power Rating
3 hp
Catalog ID
C-HC25DNJ250A
Operating Temperature
150 deg F
