EATON CHFEP120 Type CHF Ground Fault Equipment Breaker, 120/240 VAC, 20 A, 10 kA Interrupt, 1 Poles, Flag Trip

Selected CHFEP120EATON CHFEP120 Type CHF Ground Fault Equipment Breaker, 120/240 VAC, 20 A, 10 kA Interrupt, 1 Poles, Flag Trip
CHFEP120EATON CHFEP120 Type CHF Ground Fault Equipment Breaker, 120/240 VAC, 20 A, 10 kA Interrupt, 1 Poles, Flag Trip

Documents

Short Description

EATON's CH ground fault current interrupters (GFCIs) are 3/4 in wide and provide superior safety over a standard electrical outlet in areas where electricity may come into contact with water. GFCIs are required in any application near water such as kitchen countertops, bathrooms, swimming pools, hot tubs, and outdoor receptacles. They immediately break the circuit when electrical current leakage is detected, reducing the risk of shock and electrocution.

Features

  • The "panel neutral" conductor connects to the neutral bar, even though the neutral is not included in a 240 VAC load circuit, this connection is necessary to supply a 120 VAC power source to the ground fault sensing circuit
  • Single-pole is use with varying wire and voltage configurations, making them suitable for different situations
  • Switching duty rated, HACR rated
  • Add the AFCI tester and circuit analyzer to verify proper wiring in a circuit, it's the only tester with GFI function and line neutral test feature
  • 3/4 in wide per pole

Specification

Interrupt Rating
10
Number Of Poles
1
Minimum Order Qty
1
Order Interval
1
Amperage Rating
20 A
Catalog ID
C-HCHFEP120
Dimensions
6 in L x 3-1/2 in W x 1-1/4 in H
Type
Type CHF
Voltage Rating
120/240 VAC
Wire Size
14 to 6 AWG
Application
Residential and Light Commercial Application
Standard & Approvals
UL 489, HACR Listed
