EATON CHM7N7N5GS 4-Circuit Metered Ring Power Outlet Panel, 125/250 VAC, 20 A, NEMA 3R Enclosure
EATON CHM7N7N5GS 4-Circuit Metered Ring Power Outlet Panel, 125/250 VAC, 20 A, NEMA 3R Enclosure
SKU: C-HCHM7N7N5GS
Manufacturer Part Number: CHM7N7N5GS
UPC: 782114215616
Features
- Includes a factory installed insulated neutral bar with provisions for bonding when used for temporary service entrance applications
- 125 A rated meter socket
- 100% galvanized steel with baked on polyester powder coating
- Three point mounting
- One-piece case back for metered and unmetered panels
- Unique steel barrier prevents unauthorized operation of breakers when door is closed and padlocked
- NEMA 3R construction for rainproof installation
- Door swings up when opening and allows cords to remain connected when closed
- Removable upper deadfront cover for easy incoming wire connections to breaker terminals
- Lower deadfront cover can be removed for easy routing of incoming wires or receptacle changeouts
- Padlock provisions to prevent unauthorized entry
- Single-pole, 20 A breaker, 20 A at 125 VAC, two-pole, three-wire, NEMA 5-20R2GFI left position, two-pole, 20 A breaker, 20 A at 250 VAC, two-pole, three-wire, NEMA 6-20R2 center position
Specification
| Material | Galvanized Steel |
|---|---|
| Mounting Type | Surface |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Amperage Rating | 20 A |
| Enclosure Type | NEMA 3R |
| Feed Type | Top |
| Voltage Rating | 125/250 VAC |
| Type | 4-Circuit Ring |
| Receptacle Type | (2) NEMA 5-20R2GFI/NEMA 6-20R2 |
| Circuit Breaker Type | Ground Fault/Non-Ground Fault |
| Catalog ID | C-HCHM7N7N5GS |
| Includes | Neutral Bar |
| Standard & Approvals | UL 231, File No. E163588, ANSI, NEMA, NEC, ARRA, Buy American Act, RoHS Compliant |
| Application | For outdoor services, temporary power requirements at construction sites and RV parks |
