EATON EGE3090FFG Type EGE Molded Case Circuit Breaker, 600Y/347 VAC, 90 A, 18/25/35 kA Interrupt, 3 Poles, Fixed Thermal/Fixed Magnetic Trip

Selected EGE3090FFGEATON EGE3090FFG Type EGE Molded Case Circuit Breaker, 600Y/347 VAC, 90 A, 18/25/35 kA Interrupt, 3 Poles, Fixed Thermal/Fixed Magnetic Trip
EGE3090FFGEATON EGE3090FFG Type EGE Molded Case Circuit Breaker, 600Y/347 VAC, 90 A, 18/25/35 kA Interrupt, 3 Poles, Fixed Thermal/Fixed Magnetic Trip

Documents

Short Description

Series G molded case circuit breakers are designed for circuit protection needs across the globe. A complete line of user-friendly accessories and high performance interruption ratings meet a host of different applications, industry, and regional requirements. Current ratings range from 15 to 2500 A with voltage up to 690 VAC. Thermal magnetic and electronic trip units are available as well as residual ground fault and 30 mA earth leakage protection options.

Features

  • Compact design frees up panel space
  • Common field fit internal accessories make installation and custom configuration easy
  • Advanced trip unit functionality offers a wide range of adjustment for maximum flexibility
  • Patented contact design features high speed blow open action, resulting in superior performance
  • Circuit breakers significantly outperform the calculations listed in the institute of electrical and electronic engineers (IEEE) standard 1584-2002, guide for performing arc flash hazard calculations

Specification

Frame
EG
Frequency Rating
50/60
Interrupt Rating
35 kA at 240 VAC/25 kA at 415 VAC/25 kA at 480 VAC/18 kA at 600Y/347 VAC
Number Of Poles
3
Minimum Order Qty
1
Order Interval
1
Video
https://www.youtube.com/watch?v=LcFMAGwrZvM
Amperage Rating
90 A
Catalog ID
C-HEGE3090FFG
Connection Type
Line/Load
Dimensions
2.99 x 3 x 5.5 in
Enclosure Type
NEMA AB1-1993
Phase
3
Series
G Series
Temperature Rating
40 deg C
Trip Type
Fixed Thermal/Magnetic
Type
Type EGE
Voltage Rating
600Y/347 VAC
Application
Electrical, Machinery OEMs, Earth Leakage and Current Limiting Breakers Applications
Standard & Approvals
UL Listed, CE, CSA, IEC Certified, RoHS, ARRA, Buy American Act Compliant
Includes
Frame, Trip Unit, Standard Terminals
