EATON EHD2015VWD01 C Series Type EHD Molded Case Circuit Breaker, 480 VAC/250 VDC, 15 A, 14/18 kA Interrupt, 2 Poles, Fixed Thermal/Fixed Magnetic Trip
EATON EHD2015VWD01 C Series Type EHD Molded Case Circuit Breaker, 480 VAC/250 VDC, 15 A, 14/18 kA Interrupt, 2 Poles, Fixed Thermal/Fixed Magnetic Trip
SKU: C-HEHD2015VWD01
Manufacturer Part Number: EHD2015VWD01
UPC: 786679040935
Features
- Patented contact design features high speed blow open action, resulting in superior performance
- Suitable for reverse feed applications
- They have proven user acceptance for over 20 years and meet or exceed north American standards
- Without terminals
Specification
| Frame | F |
|---|---|
| Frequency Rating | 50/60 |
| Number Of Poles | 2 |
| Series | C Series |
| Type | Type EHD |
| Voltage Rating | 480 VAC/250 VDC |
| Application | Circuit Protection, Panelboard, Distribution Panels, Switchboard, Motor Control Center and Busway |
| Standard & Approvals | ARRA, Buy American Act Compliant, CSA C22.2 No. 5, RoHS Compliant, UL 489 |
| Amperage Rating | 15 A |
| Connection Type | 10-32 Line/Load Terminal |
| Dimensions | 3.38 x 2.75 x 6 in |
| Trip Type | Thermal Magnetic |
| Temperature Rating | 40 deg C |
| Material | Glass Polyester |
| Interrupt Rating | 18/14/10 |
