EATON ELC-EX08NNDN 8-Point Right Side Bus Digital Expansion Module, 24 VDC, 50 mA, 8 Inputs, 8 Outputs

Selected ELC-EX08NNDNEATON ELC-EX08NNDN 8-Point Right Side Bus Digital Expansion Module, 24 VDC, 50 mA, 8 Inputs, 8 Outputs
ELC-EX08NNDNEATON ELC-EX08NNDN 8-Point Right Side Bus Digital Expansion Module, 24 VDC, 50 mA, 8 Inputs, 8 Outputs

Short Description

The ELC modular controllers are less than half the size of most programmable logic controllers. ELC digital I/O expansion modules provide the correct amount and type of I/O for application solutions. Choose 4, 8 or 16 I/O with different combinations of AC and DC input and relay and transistor output. Any number of expansion modules can be added to an ELC controller to create up to 256 I/O. Specialty modules like analog in, analog out, and Platinum temperature are also available.

Features

  • Modular and expandable PLC's with distributed I/O capability
  • Digital, analog, thermocouple and RTD I/O
  • Relay or transistor outputs
  • High current relay output module
  • High speed pulse capture and high speed pulse output up to 200 kHz
  • Two RS-485 Modbus serial ports
  • Distributed I/O adapters for Ethernet/IP, Modbus TCP, DeviceNet, PROFIBUS DP and RS-485
  • 8 DC input
  • 8 point

Specification

Number of Inputs
8
Number of Outputs
8
Series
ELC
Temperature Rating
0 to 55 deg C
Type
Right Side Bus
Voltage Rating
24 VDC
Amperage Rating
50 mA
Dimensions
4-1/2 in L x 3-3/4 in W x 2-3/4 in H
