EATON FAZ-C3/1-SP Standard Current Limiting Supplementary Protector, 277 VAC, 48 VDC, 3 A, 15 kA Interrupt, 1 Poles, 5-10X/Thermal Magnetic Trip

Selected EATON FAZ-C3/1-SP Standard Current Limiting Supplementary Protector, 277 VAC, 48 VDC, 3 A, 15 kA Interrupt, 1 Poles, 5-10X/Thermal Magnetic Trip
EATON FAZ-C3/1-SP Standard Current Limiting Supplementary Protector, 277 VAC, 48 VDC, 3 A, 15 kA Interrupt, 1 Poles, 5-10X/Thermal Magnetic Trip

Documents

Short Description

Eaton's FAZ Supplementary Protectors provide over current protection where branch circuit protection is not required or is provided by a separate device like a fuse or molded case breaker per UL 1077. The wide range of current ratings (0.5 to 60 A) make it an ideal choice.

Features

  • Current limiting design provides fast short circuit interruption that reduces the let through energy that can damage the circuit
  • Thermal magnetic over current protection
  • Trip-free design, breaker can not be defeated by holding the handle in the on position
  • A color coded red/green indicator provides immediate visual indication of device status (green for OFF, red for on) and isolation function
  • Power to the circuit breakers can be fed from the line or load side
  • Captive screws cannot be lost
  • Small modular width of the device and accessories saves space in the panel or equipment, which can lead to cost savings
  • 5 to 10 x In (rating plug rating)

Specification

Frequency Rating
50/60 Hz
Interrupt Rating
10 kAIC
Mounting Type
DIN Rail
Number Of Poles
1
Minimum Order Qty
1
Order Interval
1
Catalog ID
C-HFAZ-C3/1-SP
Dimensions
0.69 in L
Enclosure Type
IP20
Series
FAZ
Temperature Rating
-40 to 75 deg C
Type
C-Curve
Voltage Rating
277 VAC, 48 VDC
Application
Industrial Application
Standard & Approvals
UL 1077 Listed, CSA C22.2 No. 235, RoHS Compliant
Amperage Rating
3 A
