EATON FD3080 C Series Type FD Molded Case Circuit Breaker, 600 VAC/250 VDC, 80 A, 35 kAIC at 480 VAC/65 kAIC at 240 VAC Interrupt, 3 Poles, Fixed Thermal/Fixed Magnetic Trip

Selected FD3080EATON FD3080 C Series Type FD Molded Case Circuit Breaker, 600 VAC/250 VDC, 80 A, 35 kAIC at 480 VAC/65 kAIC at 240 VAC Interrupt, 3 Poles, Fixed Thermal/Fixed Magnetic Trip
FD3080EATON FD3080 C Series Type FD Molded Case Circuit Breaker, 600 VAC/250 VDC, 80 A, 35 kAIC at 480 VAC/65 kAIC at 240 VAC Interrupt, 3 Poles, Fixed Thermal/Fixed Magnetic Trip

Documents

Short Description

Eaton Series C Molded Case Circuit Breakers are used in panelboard, switchboard, motor control center, and busway applications for dependable branch circuit protection. They have proven user acceptance for over 20 years and meet or exceed North American standards. Available for systems up to 600 VAC or 250 VDC with current ratings up to 2500 A.

Features

  • All F-frame circuit breakers are HACR rated
  • All circuit breakers 10 through 50 amperes are suitable for HID (high intensity discharge) use
  • All F-frame circuit breakers are suitable for reverse feed use
  • Fixed instantaneous trip, non-interchangeable trip units
  • Cu/Al wire

Specification

Frame
F
Frequency Rating
50/60 Hz
Interrupt Rating
25 kA
Mounting Type
Panel
Number Of Poles
3
Minimum Order Qty
1
Order Interval
1
Video
https://www.youtube.com/watch?v=ZBPV2r7VTgw&t=33s
Actuator Type
Handle
Amperage Rating
80 A
Catalog ID
C-HFD3080
Connection Type
Load Lug
Dimensions
3.38 x 4.13 x 6 in
Enclosure Type
NEMA AB1-1993
Phase
3
Series
C Series
Temperature Rating
40 deg C
Trip Type
Long Time/Instantaneous
Type
Type FD
Voltage Rating
600 VAC/250 VDC
Wire Size
14 to 1/0 AWG
Application
For panelboard, switchboard, motor control center and busway applications
Standard & Approvals
UL Listed, CSA Certified, Federal Spec. W-C-375b
