EATON HFD3100BP10 C Series Type HFD Molded Case Circuit Breaker, 600 VAC/250 VDC, 100 A, 100 kAIC at 240 VAC/65 kAIC at 480 VAC Interrupt, 3 Poles, Fixed Thermal/Fixed Magnetic Trip

Selected HFD3100BP10EATON HFD3100BP10 C Series Type HFD Molded Case Circuit Breaker, 600 VAC/250 VDC, 100 A, 100 kAIC at 240 VAC/65 kAIC at 480 VAC Interrupt, 3 Poles, Fixed Thermal/Fixed Magnetic Trip
HFD3100BP10EATON HFD3100BP10 C Series Type HFD Molded Case Circuit Breaker, 600 VAC/250 VDC, 100 A, 100 kAIC at 240 VAC/65 kAIC at 480 VAC Interrupt, 3 Poles, Fixed Thermal/Fixed Magnetic Trip

Documents

Short Description

Eaton's series C molded case circuit breakers are used in panel board, switchboard, motor control center and busway applications for dependable branch circuit protection. They have proven user acceptance for over 20 years and meet or exceed North American standards. Available for systems up to 600 VAC or 250 VDC with current ratings up to 2500 A.

Features

  • Patented contact design features high speed "blow open" action, resulting in superior performance
  • Suitable for reverse feed application
  • All Eaton's F-Frame circuit breakers are HACR rated

Specification

Frame
F
Frequency Rating
50/60 Hz
Number Of Poles
3
Minimum Order Qty
1
Order Interval
1
Amperage Rating
100 A
Catalog ID
C-HHFD3100BP10
Dimensions
3.38 x 4.13 x 6 in
Series
C Series
Temperature Rating
40 deg C
Trip Type
Thermal Magnetic/Non-Interchangeable
Voltage Rating
600 VAC/250 VDC
Application
For panelboard, switchboard, motor control center and busway
Standard & Approvals
UL 489, CSA C22.2 No. 5, AS 2184, BS 4752, IEC 60947-2, SABS 156, SEV 157-1, VDE 0660, Federal Specification W-C-375b
Type
Type HFD
Enclosure Type
NEMA AB1-1993
Video
https://www.youtube.com/watch?v=ZBPV2r7VTgw
Interrupt Rating
65 kA at 480 VAC
