Cutler-Hammer HMCP030H1C Motor Circuit Protector, 600 VAC, 250 VDC, 30 A, 3 Poles, Magnetic Trip
Cutler-Hammer HMCP030H1C Motor Circuit Protector, 600 VAC, 250 VDC, 30 A, 3 Poles, Magnetic Trip
SKU: C-HHMCP030H1C
Manufacturer Part Number: HMCP030H1C
UPC: 786679150825
Features
- NEMA 1 starter
- 6.9 to 25.2 A motor full load current amperes
- A to H cam setting
- Non-aluminum termina
Specification
| Frame | F |
|---|---|
| Number Of Poles | 3 |
| Series | C Series |
| Trip Type | Magnetic |
| Amperage Rating | 30 A |
| Dimensions | 3.38 in L x 4.13 in W x 6 in H |
| Standard & Approvals | UL 489, CE Certified, CSA C22.2 No. 5.1, IEC 157-1 |
| Voltage Rating | 600 VAC, 250 VDC |
| Trip Range | 90 to 300 A |
