EATON HMCP150T4CA02 C Series Type HMCP Motor Circuit Protector, 600 VAC, 250 VDC, 150 A, 3 Poles, Magnetic Trip
EATON HMCP150T4CA02 C Series Type HMCP Motor Circuit Protector, 600 VAC, 250 VDC, 150 A, 3 Poles, Magnetic Trip
SKU: C-HHMCP150T4CA02
Manufacturer Part Number: HMCP150T4CA02
UPC: 786679247969
Features
- NEMA 4 starter
- 34.6 to 126.7 A motor full load current amperes
- A to H cam setting
- Non-aluminum terminal
Specification
| Frame | F |
|---|---|
| Number Of Poles | 3 |
| Series | Series C |
| Trip Range | 450 to 1500 A |
| Trip Type | Magnetic |
| Voltage Rating | 600 VAC, 250 VDC |
| Standard & Approvals | UL 489, CE Certified, CSA C22.2 No. 5.1, IEC 157-1 |
| Amperage Rating | 150 A |
| Dimensions | 8 x 5 x 5 in |
| Enclosure Type | NEMA 4 |
| Includes | Left Pole Mounted 1NO-1NC HMCP Auxiliary Switch With 18 in Rear Side Pigtail Leads |
