EATON HMCPS003A0C C Series Type HMCP Motor Circuit Protector, 600 VAC, 250 VDC, 3 A, 3 Poles, Magnetic Trip
EATON HMCPS003A0C C Series Type HMCP Motor Circuit Protector, 600 VAC, 250 VDC, 3 A, 3 Poles, Magnetic Trip
SKU: C-HHMCPS003A0C
Manufacturer Part Number: HMCPS003A0C
UPC: 786679804247
Documents
Features
- NEMA 0 starter
- 0.69 to 2.5 A motor full load current amperes
- A to H cam setting
- Non-aluminum terminal
Specification
| Frame | F |
|---|---|
| Number Of Poles | 3 |
| Series | Series C |
| Trip Type | Magnetic |
| Voltage Rating | 600 VAC, 250 VDC |
| Standard & Approvals | UL 489, CE Certified, CSA C22.2 No. 5.1, IEC 157-1 |
| Amperage Rating | 3 A |
| Enclosure Type | NEMA 0 |
| Dimensions | 7.6 x 5.1 x 4.8 in |
| Trip Range | 9 to 30 A |
