EATON NS2-250-NA Type NZM Molded Case Circuit Breaker, 690 VAC, 250 A, 150 kA Interrupt, 3 Poles

Selected NS2-250-NAEATON NS2-250-NA Type NZM Molded Case Circuit Breaker, 690 VAC, 250 A, 150 kA Interrupt, 3 Poles
NS2-250-NAEATON NS2-250-NA Type NZM Molded Case Circuit Breaker, 690 VAC, 250 A, 150 kA Interrupt, 3 Poles

Documents

Short Description

Eaton’s NZM Series MCCB provides the broadest offering of circuit breakers and accessories up to 1600A and up to 150kA. The range of protection units include selective LSI electronic trip units from as low as 160A as well as motor protection with built in single phase sensitivity. Suitable for global markets, including North American UL and shipping approvals, together with a built-in enhanced diagnostic capability, the NZM is the choice of both panelbuilders and machinery OEMs worldwide.

Features

  • Molded case switch

Specification

Interrupt Rating
150 kA
Number Of Poles
3
Minimum Order Qty
1
Order Interval
1
Video
https://www.youtube.com/watch?v=PY52j05p7to
Amperage Rating
250 A
Phase
3 ph
Temperature Rating
-25 to 70 deg C
Voltage Rating
690 VAC
Application
Hazardous Location Applications
Standard & Approvals
UL 60950, cUL Listed, CSA C22.2 No. 5, CE Marked, FCC Part 15, Class A, IEC 60 947-2
EANUCC13
4015081025466
Type
Type NZM
Dimensions
5.866 in L x 4.134 in W x 7.283 in H
Connection Type
Front Screw
Catalog ID
C-HNS2-250-NA
Actuator Type
Rocker Lever
