EATON QuickLag® QC2030 Type QC Miniature Circuit Breaker, 120/240 VAC, 30 A, 10 kA Interrupt, 2 Poles, Non-Interchangeable/Thermal Magnetic Trip

Selected QC2050EATON QuickLag® QC2030 Type QC Miniature Circuit Breaker, 120/240 VAC, 30 A, 10 kA Interrupt, 2 Poles, Non-Interchangeable/Thermal Magnetic Trip
QC2050EATON QuickLag® QC2030 Type QC Miniature Circuit Breaker, 120/240 VAC, 30 A, 10 kA Interrupt, 2 Poles, Non-Interchangeable/Thermal Magnetic Trip

Documents

Short Description

Eaton has a wide selection of UL rated miniature circuit breakers for loadcenters, fuse boxes, or similar devices. Each pole provides steel frame calibration and arc chutes with 5 - 100A continuous in one-, two-, and three-pole designs. A full-range of accessories expand customization options, including various mounting and ring tung termination options.

Features

  • Wide variety of mounting styles available to install in many different applications
  • Complete line of accessories allows customization to fit any applications
  • Compact designs available to minimize panel size
  • Fixed instantaneous trip
  • Switching duty rated for 120 VAC fluorescent light applications only
  • Cu/Al wire
  • Non-interchangeable trip

Specification

Interrupt Rating
10 kA
Mounting Type
Panel
Number Of Poles
2
Phase
1
Temperature Rating
40 deg C
Trip Type
Long Time and Instantaneous
Type
Type QC Molded Case Thermal Magnetic
Voltage Rating
120/240 VAC
Wire Size
14 to 4 AWG
Application
For loadcenters, fuseboxes or similar devices
Standard & Approvals
UL 489, UL Listed, CSA Approved, HACR rated
Amperage Rating
30 A
Dimensions
3.9 in L x 3.8 in W x 4 in H
Connection Type
Cable-In/Cable-Out
