EATON XTCE018C01B Full Voltage Non-Reversing IEC Contactor, 220 to 240 VAC V Coil, 18 A, 1NC Contact, 3 Poles
EATON XTCE018C01B Full Voltage Non-Reversing IEC Contactor, 220 to 240 VAC V Coil, 18 A, 1NC Contact, 3 Poles
SKU: C-HXTCE018C01B
Manufacturer Part Number: XTCE018C01B
UPC: 782116485208
Documents
Features
- 5 kW at 220/230 VAC 3 ph, 7.5 kW at 380/400 VAC 3 ph, 10 kW at 415 VAC 3 ph 50/60 Hz coil power rating
Specification
| Frequency Rating | 50/60 Hz |
|---|---|
| Maximum Load Current | 18 A |
| Mounting Type | DIN Rail/Panel |
| Number Of Poles | 3 |
| Terminal Type | Screw |
| Type | C-Frame Full Voltage Non-Reversing |
| Standard & Approvals | BAA Compliant, RoHS Compliant, UL Listed, CSA Certified, CE Certified, EN 60947, IEC 60947 |
| Dimensions | 3.425 in L x 1.85 in W x 3.898 in H |
| Contact Configuration | 1NC |
| Size | 45 mm |
| Coil Voltage | 220 VAC at 50 Hz, 240 VAC at 60 HZ |
| Coil Power Rating | 2 hp at 115/200 VAC 1 ph, 3 hp at 230 VAC 1 ph, 5 hp at 200/230 VAC 3 ph, 10 hp at 460 VAC 3 ph, 15 hp at 575 VAC 3 ph |
| Series | XTCE |
