EATON XTCE025C10TD Full Voltage Non-Reversing IEC Contactor, 24 to 27 VDC V Coil, 25 A, 1NO Contact, 3 Poles
EATON XTCE025C10TD Full Voltage Non-Reversing IEC Contactor, 24 to 27 VDC V Coil, 25 A, 1NO Contact, 3 Poles
SKU: C-HXTCE025C10TD
Manufacturer Part Number: XTCE025C10TD
UPC: 401508277145
Short Description
Features
- Electronic coil controller allows contactors to reduce power consumption and generate less heat, resulting in lower cooling requirements, the ability to mount more contactors/starters per cabinet and an extended life on pilot devices that carry control signals
- AC and DC devices with the same dimensions achieved with an electronically controlled coil system allow for space savings and reduced engineering design time
- Integrated suppressors in DC controlled contactors offers reductions in total logistics and inventory costs by limiting the number of products ordered and stocked
- Wiring is not required, therefore increasing installation and maintenance efficiency
- Expanded range of DC coil control voltages, allows reliable operation through fluctuations in control voltages
- Twin terminals with separate sockets in contactors up to 400 A offer installation and application flexibility when using different size wires, the improved integrity of the connections reduces cabling faults
- 45 mm C-frame
- 7.5 hp at 220/230 VAC, 11 hp at 380/400 VAC, 14.5 hp at 415 VAC, 14 hp at 660/690 VAC coil power rating
Specification
| Frequency Rating | 50 Hz |
|---|---|
| Maximum Load Current | 25 A |
| Mounting Type | Panel/DIN Rail |
| Number Of Poles | 3 |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Contact Configuration | 1NO |
| Dimensions | 4 in L x 3-1/2 in W x 2 in H |
| Enclosure Type | IP20 |
| Series | XT Series |
| Coil Voltage | 230 VAC |
| Coil Power Rating | 7.5 hp |
| Catalog ID | C-HXTCE025C10TD |
| Operating Temperature | -25 to 50 deg C |
| Standard & Approvals | UL Listed, CSA, CE Certified, IEC/EN 60947-4-1, 60947-5-1 RoHS Compliant |
| Type | Type FVNR |
| Terminal | Screw |
