EATON BQ2402120 Quadplex Type BQ Molded Case Circuit Breaker, 120/240 V AC, 20 to 40 A, 10 kA Interrupt, 4 Poles, Thermal Magnetic Trip

Selected EATON BQ2402120
EATON BQ2402120

Documents

Short Description

Eaton’s BR circuit breakers are used in indoor and outdoor BR loadcenters, spa panels, meter breakers and sub panels. They are designed for a wide range of applications such as high short-circuit interrupt, series rating combinations with upstream main breakers, thermal magnetic, AFCI, GFCI, equipment protection and dual function AF/GF.

Features

  • Circuit breaker includes rejection tab and offers long time instantaneous trip to offer superior performance
  • Ideal for loadcenter applications and protects wiring from overheating or short-circuits
  • Standard interrupting capacity
  • Rejection tab feature

Specification

Wire Size
14 to 4 AWG
Type
Type BQ
Number Of Poles
4
Dimensions
3 in L x 2 in W x 3 in H
Mounting Type
Plug-On
Phase
1
Trip Type
Thermal Magnetic
Temperature Rating
60 to 75 deg C
Series
Quadplex
Interrupt Rating
10 kA
Amperage Rating
20 to 40 A
Actuator Type
Handle
Voltage Rating
120/240 V AC
Connection Type
Line/Load Lug
