EATON EGH2020FFG G Series Type EGH Molded Case Circuit Breaker With Metric Mounting Hardware, 600Y/347 VAC, 20 A, 100 kA at 240 VAC, 70 kA at 415 VAC, 65 kA at 480 VAC, 35 kA at 600Y/347 VAC Interrupt, 2 Poles, Fixed Thermal/Fixed Magnetic Trip

Selected EGH2090FFGEATON EGE2040FFG G Series Type EGE Molded Case Circuit Breaker With Metric Mounting Hardware, 600Y/347 VAC, 40 A, 35 kA at 240 VAC, 25 kA at 415 VAC, 25 kA at 480 VAC, 18 kA at 600Y/347 VAC Interrupt, 2 Poles, Fixed Thermal/Fixed Magnetic Trip
EGH2090FFGEATON EGE2040FFG G Series Type EGE Molded Case Circuit Breaker With Metric Mounting Hardware, 600Y/347 VAC, 40 A, 35 kA at 240 VAC, 25 kA at 415 VAC, 25 kA at 480 VAC, 18 kA at 600Y/347 VAC Interrupt, 2 Poles, Fixed Thermal/Fixed Magnetic Trip

Documents

Short Description

Series G molded case circuit breakers are designed for circuit protection needs across the globe. A complete line of user-friendly accessories and high performance interruption ratings meet a host of different applications, industry, and regional requirements. Current ratings range from 15 to 2500 A with voltage up to 690 VAC. Thermal magnetic and electronic trip units are available as well as residual ground fault and 30 mA earth leakage protection options.

Features

  • Compact design frees up panel space
  • Common field fit internal accessories make installation and custom configuration easy
  • Advanced trip unit functionality offers a wide range of adjustment for maximum flexibility
  • Patented contact design features high speed blow open action, resulting in superior performance
  • Circuit breakers significantly outperform the calculations listed in the institute of electrical and electronic engineers (IEEE) standard 1584-2002, guide for performing arc flash hazard calculations

Specification

Frequency Rating
50/60 Hz
Number Of Poles
2
Minimum Order Qty
1
Order Interval
1
Amperage Rating
20 A
Connection Type
Line/Load
Enclosure Type
NEMA AB1-1993
Phase
1
Temperature Rating
40 deg C
Trip Type
Fixed Thermal/Fixed Magnetic
Standard & Approvals
UL Listed, CE/CSA/IEC Certified, RoHS Compliant, ARRA Compliant, Buy American Act Compliant
Voltage Rating
600Y/347 VAC
Type
Type EGH
Series
G Series
Dimensions
2.99 in L x 2 in W x 5.5 in H
Catalog ID
C-HEGH2020FFG
Interrupt Rating
100 kA at 240 VAC, 70 kA at 415 VAC, 65 kA at 480 VAC, 35 kA at 600Y/347 VAC
Frame
EG
Includes
Frame, Trip Unit, Standard Terminals
Application
Electrical, Machinery OEMs, Earth Leakage and Current Limiting Breakers Applications
