EATON GHQ2030 C Series Type GHQ Molded Case Circuit Breaker, 277/480 V AC, 30 A, 14 kA Interrupt, 2 Poles

Selected IDW IMAGE df1fef801ae6498da2615a6b3e9be72108849d086476d0f30cbf68e2df225415
IDW IMAGE df1fef801ae6498da2615a6b3e9be72108849d086476d0f30cbf68e2df225415

Documents

Short Description

Eaton has a wide selection of UL rated miniature circuit breakers for loadcenters, fuseboxes, or similar devices. Each pole provides steel frame calibration and arc chutes with 5 - 100A continuous in one-, two-, and three-pole designs. A full-range of accessories expand customization options, including various mounting and ring tung termination options.

Features

  • Patented contact design features high speed "blow-open" action resulting in superior performance
  • Circuit breakers significantly outperform the calculations listed in The Institute of Electrical and Electronic Engineers (IEEE) standard 1584-2002, guide for performing arc flash hazard calculations
  • All G-frame circuit breakers are suitable for reverse feed use
  • 14 kA at 277 VAC interrupt rating

Specification

Frequency Rating
50/60 Hz
Number Of Poles
2
Series
C Series
Voltage Rating
277/480 V AC
Type
Type GHQ
Interrupt Rating
14 kA
Dimensions
12 in L x 7-1/2 in W x 4-1/2 in H
Frame
G
Amperage Rating
30 A
