EATON PSG240E 1-ph Low Profile DC Power Supply, 100 to 240 VAC, 85 to 264 VAC, 100 to 375 VDC Input, 24 VDC Output, 240 W Power Rating, 2.9 A, DIN Rail Mount

Selected PSG240EEATON PSG240E 1-ph Low Profile DC Power Supply, 100 to 240 VAC, 85 to 264 VAC, 100 to 375 VDC Input, 24 VDC Output, 240 W Power Rating, 2.9 A, DIN Rail Mount
PSG240EEATON PSG240E 1-ph Low Profile DC Power Supply, 100 to 240 VAC, 85 to 264 VAC, 100 to 375 VDC Input, 24 VDC Output, 240 W Power Rating, 2.9 A, DIN Rail Mount

Documents

Short Description

Eaton's PSL general purpose power supplies are single-phase, low-profile and can be mounted on standard DIN rail. The devices offer IEC Class II double insulated protection, which means that no earth connection is required, resulting in low leakage current and a longer lifespan. PSL power supplies are designed for use in compact cabinets for home automation, panel shops, food and beverage, and HVAC applications, communication networks and sensors.

Features

  • Varistor transient surge voltage, surge voltage protection against internal surge, safety class 1 with ground connection, fingersafe cover
  • -20 to 75 deg C operating temperature
  • 2.9 A input, 10 A output, 15 A surge rated operational current
  • Heavy duty screw terminals
  • Ratings for 1-phase are at 115 V, 0 Hz at DC input

Specification

Frequency Rating
47 to 63 Hz
Height
4.67 in
Input Voltage
100 to 240 VAC, 85 to 264 VAC, 100 to 375 VDC
Mounting Type
DIN Rail
Output Voltage
24 VDC
Power Rating
240 W
Standard & Approvals
RoHS Compliant, IEC Standard, EN Listed, cULus Listed, UL File No. 60950-1, CSA Certified, UL 508, cUL Listed, CE Certified, German Safety Compliant, PROP65: This product can expose you to chemicals including: Nickel compounds which is known to the State of California to cause cancer and Bisphenol A (BPA) which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Application
Electrical Assemblies, Panels and OEMs, Backup Power and Electronic Power Conversion Applications
Width
3.35 in
Type
1-ph Low Profile
Series
PSG
Depth
4.76 in
Case Material
Aluminum
Amperage Rating
2.9 A
