EATON TR1107B-BOX Duplex Decorator Straight Blade Tamper Resistant Grounding Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, Brown
EATON TR1107B-BOX Duplex Decorator Straight Blade Tamper Resistant Grounding Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, Brown
SKU: EAGTR1107B-BOX
Manufacturer Part Number: TR1107B-BOX
UPC: 032664752490
Documents
Short Description
Features
- Longer, wider bridged strap provides 40% more contact area with wallboard, virtually eliminating floating installations
- Patented built-in wire looper for pre-looping
- Double wipe ground contacts ensure long-term ground retention
- Easy access split circuit break off tab
- Tri-combo screws accept slotted, Phillips and Robertson head tools for installation flexibility
- Flush mounting
- Push and side wire connection
- 14 to 10 AWG wire size
- Standard grade
- Impact resistant thermoplastic
Specification
| Material | Thermoplastic |
|---|---|
| NEMA Rating | NEMA 5-15R |
| Number Of Poles | 2 |
| Number of Wires | 3 |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Amperage Rating | 15 A |
| Catalog ID | EAGTR1107B-BOX |
| Color | Brown |
| Series | Decorator |
| Voltage Rating | 125 VAC |
| Temperature Rating | -4 to 158 deg F |
| Dimensions | 4.193 in H x 1.015 in D |
| Video | https://www.youtube.com/watch?v=wVyZtLMLREA |
| Grade | Standard |
| Standard & Approvals | cULus, UL 498 File No. E15058 Listed, NOM Certified, RoHS Compliant |
| Terminal Type | Screw/Back/Side Wire |
| Type | Straight Blade |
