Edwards Signaling™ 590 Class 2 Low Voltage Signaling Transformer, 120 VAC Primary, 10 VAC Secondary, 0.005 kVA, 50/60 Hz

Selected 590Edwards Signaling™ 590 Class 2 Low Voltage Signaling Transformer, 120 VAC Primary, 10 VAC Secondary, 0.005 kVA, 50/60 Hz
590Edwards Signaling™ 590 Class 2 Low Voltage Signaling Transformer, 120 VAC Primary, 10 VAC Secondary, 0.005 kVA, 50/60 Hz

Documents

Short Description

Edwards 590 Series Class 2 Signaling Transformers are easy to install, low voltage power sources for residential, commercial, and industrial uses. Mounts in a standard 1/2 in (13mm) knockout or surface mounts using the provided foot mounts. These transformers are suitable for mounting in both plastic and metal back boxes. May also be used with the Cat. No. 593 transformer plate for enclosed mounting in a standard two gang outlet box. The Edwards 590, 590Y & 591 transformers are used in light duty applications. They are ideal for standard doorbells and chimes in residential and commercial applications.

Features

  • Non-regenerative thermal overload protection
  • Grounding wire
  • Pre-stripped primary side pigtails
  • Screw terminal connections on secondary

Specification

Frequency Rating
50/60 Hz
Mounting Type
Surface
Power Rating
5 VA
Primary Voltage
120 VAC
Standard & Approvals
CSA Certified, UL Listed
Dimensions
2-5/16 in L x 2-1/4 in W x 2-1/8 in H
Application
For Residential, Commercial and Industrial Applications
Type
Low Voltage Class 2
Series
590
Secondary Voltage
10 VAC
