Ericson® Perma-Link® 1630-CH 1-Phase Straight Blade Connector With Gray Cover, 125 VAC, 15 A, 2 Poles, 3 Wires, White

Selected Ericson® Perma-Link® 1630-CH 1-Phase Straight Blade Connector With Gray Cover, 125 VAC, 15 A, 2 Poles, 3 Wires, White
Ericson® Perma-Link® 1630-CH 1-Phase Straight Blade Connector With Gray Cover, 125 VAC, 15 A, 2 Poles, 3 Wires, White

Documents

Short Description

The same rugged internal construction as our standard Perma-Link® line is found in these units and in addition they meet UL hospital grade standards. Designed for reliable long life, built to withstand exceptional abuse, these dead front, back wired devices save installation time, provide maximum protection and can be used for straight blade installations in hospitals, schools and extended care facilities. Constructed of rugged polybutylene terephthalate (PBT) and a high tech thermoplastic elastomer (TPE), they have passed tests for ground pin retention, ground resistance, face impact, ground temperature contact, fault current, line blade retention and abrupt removal.

Features

  • White and light institution gray colors identify this style which provides superior insulation
  • They are clearly marked hospital grade and clearly marked with a green dot to signify UL hospital grade
  • Non-conductive cord clamp to accommodate cord sizes (3) 16 AWG SJ through (3) 12 AWG SO sizes
  • Rugged rubberized grip, solid brass blade, weather resistant

Specification

Grade
Hospital
NEMA Rating
NEMA 5-15R
Number Of Poles
2
Number of Wires
3
Type
1-Phase
Voltage Rating
125 VAC
Standard & Approvals
ARRA Compliant, Buy American Act Compliant, RoHS Compliant, UL Listed, CSA Certified
Amperage Rating
15 A
Color
White
Application
Indoor, Hospitals, Schools and Extended Care Facilities
Terminal Type
Dead Front Back Wired
Temperature Rating
-20 to 100 deg C
Material
PBT/Thermoplastic Elastomer
