Federal Signal StreamLine® LP3P-120R LP3P Low Profile Strobe Light, 120 VAC, Strobe Tube Lamp, Red, Surface Mount, ARRA Compliant|BAA Compliant|CSA Certified|cUL Listed, 4X/IP66/IP69K NEMA Rating

Federal Signal StreamLine® LP3P-120R LP3P Low Profile Strobe Light, 120 VAC, Strobe Tube Lamp, Red, Surface Mount, ARRA Compliant|BAA Compliant|CSA Certified|cUL Listed, 4X/IP66/IP69K NEMA Rating
SKU: FEDLP3P-120R
Manufacturer Part Number: LP3P-120R
UPC: 782979203360
Documents
Short Description
Features
- Federal signal Fireball® strobe is a very low maintenance warning light for industrial applications where a vibration-resistant light is required to signal an emergency or process status
- Fireball® features a unique dome that twists off easily for quick dome and lamp replacements
- Features an integrated 1/2 in NPT pipe mount base as well as the three holes required for surface mount configurations
- Fireball® dome and base design provides a watertight, dust tight and corrosion-resistant type 4X rating
- Fireball® can be used in any application where a superior visual signal is needed
- Especially effective in industrial hazard warning, process control, status indication and in areas with high ambient noise levels
- Corner bracket and wall bracket fixture
- Black epoxy paint is electrostatically applied to the base for superior corrosion resistance
- 1/2 in NPT pipe/surface mounting
- NEMA 4X, IP66 enclosure
Specification
| Average Life | 4000 hr |
|---|---|
| Flash Rate | 80 fpm |
| Specifications Met | ARRA Compliant|BAA Compliant|CSA Certified|cUL Listed |
| Housing Material | Polycarbonate |
| NEMA Rating | 4X/IP66/IP69K |
| Diameter | 3-1/8 in |
| Voltage Rating | 120 VAC |
| Type | Low Profile |
| Temperature Rating | -31 to 150 deg F |
| Color | Red |
| Dimensions | 3.13 in W x 3.13 in D x 5.82 in H |
| Mounting Type | Surface |
| Light Output | 175000 cd |
| Shape | Cylindrical |
| Lamp Type | Strobe Tube |
| Series | LP3P |
| Amperage Rating | 0.1 A |
