Mersen AMP-TRAP® 2000 SmartSpot® A6D10R Current Limiting Low Voltage North American Time Delay Power Fuse, 10 A, 600 VAC, 200 kA Interrupt, RK1 Class, Cylindrical Body

Selected Mersen AMP-TRAP® 2000 SmartSpot® A6D10R Current Limiting Low Voltage North American Time Delay Power Fuse, 10 A, 600 VAC, 200 kA Interrupt, RK1 Class, Cylindrical Body
Mersen AMP-TRAP® 2000 SmartSpot® A6D10R Current Limiting Low Voltage North American Time Delay Power Fuse, 10 A, 600 VAC, 200 kA Interrupt, RK1 Class, Cylindrical Body

Documents

Short Description

The Amp-Trap 2000® SmartSpot A2D-R and A6D-R fuses feature a visual open fuse indicator and provide IEC Type 2 No Damage protection to main, feeder, and branch circuits for all types of loads. With time-delay characteristics for handling harmless inrush currents, current-limiting ability and a wide range of ratings (from 1 to 600 A), A2D-R and A6D-R fuses give excellent protection for all your applications.

Features

  • Solid state SmartSpot visual blown fuse indicator
  • Time-delay for motor starting and transformer inrush currents without nuisance opening
  • Extremely current-limiting for low peak let-thru current
  • Easy 2-to-1 selectivity for prevention of nuisance shut downs and "black outs"
  • Rejection-style design prevents replacement errors
  • High-visibility orange label gives instant recognition
  • Reduced inventory by taking the place of Class RK5, K, and H fuses
  • Metal embossed date and catalog number for easier traceability and lasting identification
  • Fiberglass body provides dimensional stability in harsh industrial settings
  • High grade silica filler ensures fast arc quenching
  • Recommended for arc flash energy reduction
  • A6D-R fuses will open fast enough under extreme fault conditions for maximum short
  • Plated terminals
  • Arc Flash mitigating
  • North American power fuses
  • 200 kA at 600 VAC, 100 kA at 600 VDC interrupt rating

Specification

Interrupt Rating
200/100 kA
Material
Polyester
Mounting Type
Holder
Minimum Order Qty
1
Order Interval
1
Body Size
13/16 in Dia x 5 in L
Body Style
Cylindrical
Class
RK1
Element
Dual
Series
A6D-R
Terminal Type
Ferrule
Type
Time Delay
Voltage Rating
600 VAC
Application
Motors, Safety Switches, Transformers, Disconnects, Control Panels and All General Purpose Circuits
Amperage Rating
10 A
Catalog ID
GOUA6D10R
Standard & Approvals
UL 248-12 File E2137, DC UL 248, CSA C22.2 No. 248.12
