Mersen Amp-Trap® A6T125 Current Limiting Low Voltage Fast Acting Fuse, 125 A, 600 VAC/300 VDC, 100/200 kA Interrupt, T Class, Cylindrical Body

Selected Mersen Amp-Trap® A6T125 Current Limiting Low Voltage Fast Acting Fuse, 125 A, 600 VAC/300 VDC, 100/200 kA Interrupt, T Class, Cylindrical Body
Mersen Amp-Trap® A6T125 Current Limiting Low Voltage Fast Acting Fuse, 125 A, 600 VAC/300 VDC, 100/200 kA Interrupt, T Class, Cylindrical Body

Documents

Short Description

Fast-acting A6T Class T fuses combine two highly desirable features - high current limitation and a small physical size. Their unique dimensions prevent the substitution of other fuses with lower voltage ratings or current-limiting capability. These fuses have glass melamine bodies for superior dimensional stability and catalog numbers stamped into the blades for permanent identification.

Features

  • Extremely current-limiting for low peak let-thru current
  • Unique dimensions prevent replacement by other fuse classes
  • Blade-stamped catalog numbers for permanent identification
  • Small physical size for greater design flexibility
  • 200 kA at 600 VAC, 100 kA at 300 VDC interrupt rating

Specification

Interrupt Rating
200/100 kA
Material
GMG
Mounting Type
Clip
Series
A6T
Terminal Type
Blade
Type
Fast Acting
Voltage Rating
600 VAC/300 VDC
Standard & Approvals
UL 248-15 File E2137, DC UL 248 Listed, CSA C22.2 No. 248.15 Certified
Amperage Rating
125 A
Application
Load Centers, Panelboards, Switchboards, Circuit Breakers and Metering Centers
Body Size
1.07 in Dia x 3.26 in L
Body Style
Cylindrical
Class
T
Element
Single
