Mersen AMP-TRAP® 2000 SmartSpot® AJT100 Current Limiting Low Voltage North American Time Delay Power Fuse, 100 A, 600 VAC, 200 kA Interrupt, J Class, Cylindrical Body

Selected Mersen AMP-TRAP® 2000 SmartSpot® AJT100 Current Limiting Low Voltage North American Time Delay Power Fuse, 100 A, 600 VAC, 200 kA Interrupt, J Class, Cylindrical Body
Mersen AMP-TRAP® 2000 SmartSpot® AJT100 Current Limiting Low Voltage North American Time Delay Power Fuse, 100 A, 600 VAC, 200 kA Interrupt, J Class, Cylindrical Body

Documents

Short Description

Amp-Trap 2000 time-delay AJT fuses provide IEC Type "2" (No Damage) protection to main, feeder, and branch circuits, for all types of loads - yet, they require only half the mounting space needed for 600V UL Class RK fuses. Time-delay characteristics handle motor inrush currents without nuisance trips. Its current-limiting ability and wide range of ratings provide excellent over current protection for all your applications. An optional mechanical blown fuse indicator and Micro switch is available on blade-type (70 to 600A) fuses for visual and/or remote blown fuse indication.

Features

  • Solid state SmartSpot visual blown fuse indicator
  • Time-delay for motor starting and transformer inrush
  • Extremely current-limiting for low peak let-thru current
  • Most current-limiting UL class fuse
  • Small footprint requires less mounting space and allows smaller, more economical fuse blocks
  • Easy 2-to-1 selectivity for prevention of nuisance shutdowns
  • High-visibility orange label gives instant recognition
  • Metal embossed date and catalog number for traceability and lasting identification
  • Fiberglas body provides dimensional stability in harsh industrial settings
  • High grade silica filler ensures fast arc quenching
  • Arc flash mitigating
  • North American power fuses

Specification

Interrupt Rating
200/100 kA
Material
GMG
Mounting Type
Holder
Series
AJT
Terminal Type
Knife Blade
Type
Current Limiting
Voltage Rating
600 VAC
Application
Motor Circuits, Mains, Feeders, Branch Circuits, Lighting, Heaters, Transformers, Control Panels, Circuit Breaker Back-up, Bus Duct and Load Centers
Standard & Approvals
UL 248-8, UL File No. E2137, CSA C22.2 No. 248.8, IEC 269-2-1, RoHS Compliant
Amperage Rating
100 A
Body Size
1-1/16 in Dia x 4-5/8 in L
Body Style
Cylindrical
Class
J
Element
Dual
